Ultra-low Power Consumption Waterproof Photoelectric Beam Detector with Solar Battery for Solar Power Alarm System SWB-10SP

Features:Product Features:1. Original design, solar-powered, digital frequency c

  • Commodity name: Ultra-low Power Consumption Waterproof Photoelectric Beam Detector with Solar Battery for Solar Power Alarm System SWB-10SP
  • Product Details
  • 20160809031406864.jpg

    Features:
    Product Features:
    1. Original design, solar-powered, digital frequency conversion, lighting, infrared, radio frequency emission as a whole, entirely without wiring, installation more convenient, the provincial timber save time and effort, safer hidden prevention.
    2. quad-band frequency conversion, multiple power adjustments, multiple installation without disturbing each other, blocking any two adjacent beam will alarm, effectively prevent false positives, false negative phenomenon, higher stability.
    3. Ultra-low power consumption: unique circuit design, use digital inverter technology and DSP processing technology to overcome the traditional power consumption characteristics.
    4.Solar back-up battery capacity, small size, can sustainable work 20 days in rainy weather;
    5. Diameter Ф80mm/140mm, PC outer cylinder, all-metal stent structure, strong and durable.
    6. Fully waterproof structure can be installed in low-lying wet areas.
    7. Have tamper, anti-shear and fault self-test function design, effectively prevent vandalism, safer and more reliable.
    8. Special optical structure with automatic gain circuit, can adapt to a variety of inclement weather.



    Technical parameters
    Product Model: SWB-10sp/20sp/30sp/50sp/75sp (the S number of beams 4, 6, 8, 10)
    2 Operating voltage: 3.3V/DC
    3 Working current: Spotlights: 7mA light receptor: 2mA
    4 Reaction speed: <0.1sec
    5 Carrier frequency: 38KHZ
    6 Emission frequency: 315MHZ/433MHZ (1000 meters) 230MHZ (3000-5000)
    7 Solar cells: Ф140mm Series: 15W 380 * 370 * 25mm
    Ф80mm Series: 10W 335 * 312 * 25mm
    8. Backup battery capacity: 12AH/3.7V
    9 Ambient temperature: -25 ℃ ~ 55 ℃
    10. Ambient humidity: 0 to 75% RH (non-condensing)
