SWB-30 2 to 10 Beams (Outdoor) 30 to 150 Meters SWB-30 Photoelectric Beam Detector

Features:Product Features:* Country originated ultra-long-range* Single / dual b

  • Commodity name: SWB-30 2 to 10 Beams (Outdoor) 30 to 150 Meters SWB-30 Photoelectric Beam Detector
  • Product Details
  • 5b10aa55cdaba.jpg
    Features:
    Product Features:
    * Country originated ultra-long-range
    * Single / dual beam trigger alarm optional.
    * Four-channel frequency conversion, and higher reliability.
    * controlled by CPU, lighting linkage output.
    * Diameter φ140, new steel frame structure, durable.
    * Lighting shape, combine lighting and burglar, hidden and more secure.
    * allow installing in low-lying wet areas, as the bottom is sealed
    *Special optical structure with automatic gain circuit, can adapt to a variety of inclement weather.
    * Align with the status indicator, debugging calibration more intuitive

    Technical parameters
    1. Model: SWB-30/50/75/100/150
    2. Detection range: (outdoor) 30 to 150 meters
    3. Beam: 2 to 10 beams
    4. Heights: 63 to 223 cm
    5. Operating voltage: DC12 ~~ 18V
    6. Reaction speed: <0.1sec
    7. Working current: single throw light ≤ 45mA
    double throw light ≤ 90mA
    single light receiver ≤ 60mA
    dual light receiver ≤ 120mA
    8 relay contact capacity: 30VAC/DC, 0.5A max
    9. Ambient temperature: -25 ℃ ~ 55 ℃
    10 alarm outputs: open circuit time ≥ 1.5sec
