REF-50D :Dual-tech PIR+MW Detector With Mirror

Features:

* Dual element PIR detection technology

* Adopts multi-grades intelligent processing software, full analysis and processing of all kinds of false alarm

* Adopts micro power-consumption 8 digits CMOS single chip control

* Refined mirror，can transport the infrared energy from different distance to PIR, which can recognize the true alarm signal from false alarm effectively.

* MW anti-masking technology, can detect the attempt of blocking MW or PIR channel.

* 3 colors LED display, can recognize signals of PIR, MW, anti-masking and troubles.

* Unique anti-masking and trouble output.

* AND/OR modes for option, fit for various kinds of environments.

* MW range adjustable.

* With high/low sensitivity selection

* Unique full-range temperature compensation technology.

* Anti strong EMI interference

* EI control mode for option

Parameter:

Model REF-50D REF-50D-LF

MW frequency 10.525GHz 2.45GHz

Detection distance 12m

Installation height 1.5m-2.4m

Operation voltage/current 9-16V/DC 20mA

Sensitivity L/H for option

RFI/EMI protection >3V/m 500MHz

Alarm output 100mA/24V

Anti-mask /trouble output 100mA/24V

Tamper output 300mA/24V

Operation temperature -20℃/+40℃

Operation humidity 5%-95%（RH）

Anti white light >10000LUX

Operation mode EI mode, dual-tech mode or single-tech modes for option.

Detection speed 0.2m/s to 3.5m/s

Pet immunity 30Kg
