STB-40F8

SpecificationModel NO.STB-40F8Alarm Output Time1.5sAlarm Output Capacity1A/120V

  • Commodity name: STB-40F8
  • Product Details

  • Specification

    Model NO.
    STB-40F8
    Alarm Output Time
    1.5s
    Alarm Output Capacity
    1A/120V AC 2A/24V DC
    Lens
    Spherical Fresnel Lens
    Alarm Output Contact
    No&Nc
    Operation Voltage
    DC 10.8_18V
    Transport Package
    Paper Carton
    Specification
    CE
    Trademark
    Sunlit Tech
    Origin
    China
    HS Code
    8531100000
    Production Capacity
    50000sets/Month


    Front View


    STB-100F8 P.jpg


    Back View: Stainless steel bracket installed
    Active Infrared 2 Beams Detector with 8 Frequencies for Boundary Protection, 40m Distance Outdoor
    Inside Structure: TX: transparent lens; RX: black lens     Active Infrared 2 Beams Detector with 8 Frequencies for Boundary Protection, 40m Distance Outdoor
    Terminals for cable connection

    Parameter:

    Model

    STB-20F8

    STB-40F8

    STB-60F8

    STB-80F8

    STB-100F8

    Distance(outdoor)

    20m

    40m

    60m

    80m

    100m

    Operation current

    40mA

    50mA

    50mA

    70mA

    80mA

    Operation voltage

    DC 10.8-18V

    Lens

    Spherical Fresnel lens

    Response time

    50-700ms

    Alarm output time

    1.5s

    Alarm output contact

    NO&NC

    Alarm output capacity

    1A/120V AC   2A/24V DC

    Beams adjustment

    V: 20°(±10°) H: 180°(±90°)

    Operation temperature

    -25°C~+55°C

    Weight

    600g




    Active Infrared 2 Beams Detector with 8 Frequencies for Boundary Protection, 40m Distance Outdoor


    Product Description



    * Adopts unique spherical Fresnel lens, more powerful in light focusing
    * New filtering structure to multi-layer sundry lights, stronger capacity of anti-interference
    * Multi-grade thundering-defending system, more dependable for outdoor usage
    * Super stable digital two infrared beams with frequencies and pulse synchronization
    * Fully airproof structure, effective water-proof, dustproof and insects-proof
    * Beams response time adjustable, fit for various environments
    * Integrative optical collimating mirror, more accurate and convenient adjustment
    * LED display for calibration, convenient for installation and adjustment
    * 8 Frequencies For Option To Avoid Same Frequency Interference.
    * Adopts imported PC material with high strength for housing, more elegant and durable, better prevention for vicious damage
    * Horizontal adjustment: 180° ; Vertical adjustment: 20°
